Passive Signal Amplifier                                                                                              please send your inquiries toinfo@schmid-m.com



Series Number Remark Input Isolation (VDC) Output Package
STxxyyCP

Positive and Negative Signal

Input & Positive and

Negative Signal Output

±5, ±10V 2500 ±5, ±10V DIP24
STMxxyyCP

Positive and Negative Signal

Input & Positive and

Negative Signal Output

±10/±20/±30 ±50/±75

±100mV

2500 ±5, ±10V DIP24
STMxxyyP mV-Level Signal Amplifier

0~10/20/30 50/75/100mV

2500 5V/10V DIP24
STxxyyAP

Positive and Negative Signal

Input & Positive Signal Output

±5, ±10V 2500 0-5V/10V DIP24
STxxyyAD

Active high precision isolated

Transmitter current signal input
current Signal Output

Signal 0-2V 2500

0/4-20mA

0-5V/10V

DIP24





Isolated Transmitter General Active



Series Number Remark Input Isolation (VDC) Output Package
ST1100RN/RNS/N/NS

Passive

(Input loop power supply

4-20mA 3000 4-20mA DIP16/SMD16
ST1100L-F

Passive

(Input loop power supply

4-20mA 3000 4-20mA SIP12
