AC / DC Converter 1-5 Watt
PCB Montage
| Watt | Input VAC | Output VDC | Isolation |
Package
|
Type |
|
1 |
85-305
|
+YY | 3kV | PCB | SLD01(02)-10B |
| 2 |
85-305
|
+YY | 3kV | PCB | SLD02-10BYY |
|
85-305
|
4kV | PCB | SLDE02-23BYY | ||
| 3 | 85-264 | PCB, EE20 Transformer | SASQ03 | ||
| 2,5-5 | 85-264 | -- | PCB, EI30 Transformer | SASQ05 | |
| 3 | 85-305 | +YY | 3kV |
PCB ultra miniature open frame |
SLS03-SR2S |
| 85-305 | 4kV | PCB 1x1 | SLD03-23BxxR5 | ||
| 90-528 | 3kV |
PCB, Din Rail, Chassis |
SLD03-16Bxx | ||
| 85-305 | 3kV | open frame | ACW03-23S | ||
| 85-305 | 4kV | Wire Package | SLD03-23BxxWR2 | ||
| 5 |
85-265
|
3kV | PCB | S05AR | |
| 85-305 | 3.3 - 24Vdc | 4kV |
PCB 1x1, Din Rail, Chassis |
SLD05-23BxxR5 | |
|
85-305
|
3.3 - 24Vdc | 3kV | open frame | SLS05-13BxxR3 |
